Test Services

D-Coax offers RF/Microwave test services for your researchprojects, as well as, production quantities tests.  We have available resources and expertise in the high frequency interconnects testing that will benefit your research and products.  We will work with you to make your requested tests the most accurate and reliable and we'll complete them in a timely fashion.

The following parameters can be characterized or tested to specifications with our test services:

Time Domain:  Impedance, Impedance profile, rise time, propagation delay, skew and more.

Frequency Domain: S21 - Insertion loss, S11- Return loss, S12 - Reverse Insertion loss (port 2 insertion loss), S22 - Reverse Return loss (port 2 return loss) and more.

Engineering Services

In addition to test services, D-Coax offers consulting for your research, design of a custom connector or interconnect, or a test fixture for your product, custom calibration kits, prototyping, and assembly of the products and fixtures. We also can troubleshoot your prototype or product to find the weak points of the design and engineer solutions for the desired fidelity.  With our tool room quality machine shop the prototypes of new products or the modification of products, needing optimization, can be accomplished very quickly.

Testing Capabilities

D-COAX has the following testing capabilities:

Frequency Domain;  bandwidth  40MHz – 65GHz
Time Domain: FFT from S-parameters, 5.4ps
Rise Time
Time Domain : Step pulse, 17.5ps rise time
d-coax testing capabilities

Test Equipment

D-COAX has the following equipment dedicated to test services:

Anritsu 40MHz -65GHz Vector Network Analyzer
with (TDR) Time Domain Reflectometry
Anritsu 2.92mm Calibration KitAnritsu 1.85mm
Calibration Kit
Tektronix DSA8200 digitizing oscilloscope
Tektronix 80E04 20GHz sampling module
D-COAX Model W2.5 x L6.5 probe station
D-COAX Model D14 probe station
GGB Industries ISS (Impedance Standard Substrate)
GGB Industries 40A-GSG-150-P wafer probes
D-COAX microwave semi-rigid cables
D-COAX microwave flexible cables

Test Data Formats

  1. Quick data (no report):
    • Anritsu 40MHz -65GHz Vector Network Analyzer data:  .BMP (waveform capture),.TAB (tabulated data), .S2P (used for touchstone modeling program)
    • Tektronix DSA8200 data: .BMP files (screen capture with set measurements or specifications)
  2. Full report: description of test setup, drawings, diagrams, waveforms as necessary, data analysis,raw data, Pass/Fail spec determination, summary, conclusion

The VNA data has the measurements of:
S21: Insertion lossS11: Return loss
S12: Reverse Insertion loss (port 2 insertion loss)
S22: Reverse Return loss (port 2 return loss)

The VNA graph types are: Log Magnitude, Phase, Smith Chart (impedance), SWR, Group Delay, Smith Chart (admittance), Linear Polar, Log Polar, Linear Magnitude, Real, Imaginary.

The TDR has measurements of mV, rho and Ohms versus time that can be used in the reflection or transmission modes. The TDR measurement set is:
- Amplitude Measurements (Amplitude, High, Low, Min, Max, Mid, +Overshoot, -Overshoot and more)
- Timing Measurements (Rise Time, Fall Time, Delay, Jitter, Crossing (%, Level, Time) and more)
- The impedance can be tested to the set specifications or characteristic impedance can be calculated  for from the impedance profile.

The raw data can be transmitted electronically or on CD, the full report is a PDF document which can be transmitted electronically.

Test Services Rates

d-coax test services rate chart

The calibration is for the 1.85mm or 2.92mm calibration kit which the phase andmagnitude are zero at the reference plane.

In the case where the DUT connector has no calibration kit available, the calibrationwill be performed at the reference plane where the calibration standards are connected, but willINCLUDE the adapters in the device under test (DUT) data.

When D-COAX is in the process of building adapters, fixtures, calibration kits,calibration coefficients, etc., D-COAX will charge for that time at the D-COAX listed rates,but D-COAX owns these devices unless prior arrangements have been made before the work begins.Different rates apply for devices for sale and are quoted upon request.

Request A Quote

Engineering Services Rates

d-coax engineering services rate chart

Why use D-COAX Test Services or D-COAX Engineering Services?

The testing at D-COAX is done using some of the best equipment available with the most accuracy, repeatability, and affordability in mind. But it does not stop there because many services provided by D-COAX are not available at competitive Labs. Engineering services are available for the characterization and optimization of your product. We can assist you with the conceptual design, actually machining and testing the prototype and all the way through to the fine tuning and final design of the product.

There are common roadblocks encountered during new product design and the expert staff at D-COAX will help you overcome each obstacle.

why use d-coax chart


For any of our services, a custom Pricing Quotation is required. Click here to contact us.


Up-front payment is required before any services are provided. Payment with order, Visa/MC …Check. D-COAX accepts purchase order upon receipt of financial statement and payment history.

Lead Time:

Lead-time depends on the type of service rendered and will be estimated in the quote.
